Belkin A3L980bt01MBLUS Cat6 Network Cables (1M) – Blue (

Belkin Cat6 Network Cables (1M) – Blue (A3L980bt01MBLUS)

At a Glance
Maximise your network speed with a 7-foot high-bandwidth CAT6 cable. Learn More
Ideal for VoIP, video, and file transfers
Exceeds 500MHz in performance tests
Belkin 2 year warranty
Compatibility
Compatible with Ethernet enable devices.
Technical Specifications
Cable Characteristic
Unshielded twisted pair (UTP)
Cable Type
Cat 6
Characteristic Impedence
100±15Ω @ 1 ~ 550MHz
100±15Ω @ 1 ~ 550MHz
Conductor Construction
Bare Stranded Copper
Conductor Resistance
93.8Ω/km/20°C max
Conductor Size
24AWG x 4pairs
Connector on First End
1 x RJ-45 – male
Connector on Second End
1 x RJ-45 – male
Connectors
RJ45
Dielectric Strength
AC 1.5kV
Flame Retardant Test
CM
Insulation Material
HDPE
Jacket Diameter
5.9±0.15mm
Jacket Material
PVC
Mutual Capacitance
56pF/m max
Propagation Delay
536nS/100m max @ 550MHz
Spark Test
2.5kV
Standards Compliance
ISO/IEC 11801; TIA/EIA-568-B.2-1
Structural Return Loss
8.6dB min at 550MHz
Limited Warranty
Belkin offers CAT5e and CAT6 copper cables and connectivity products that feature quality components and utilise advanced manufacturing techniques to ensure consistent, top-quality network performance. All Belkin cables are certified and tested to exceed the industry cabling standards, and come with a 2 year warranty.
